    14 Head Weighing Vertical Packaging Machine For Candy

    Ask Lasest Price
    Brand Name : OEM
    Model Number :
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 100 sets/month
    Delivery Time : 18-25 working days
    • Product Details
    • Company Profile

    14 Head Weighing Vertical Packaging Machine For Candy

    14 Head Weighing Vertical Packaging Machine For Candy


    Characteristics:


    1. Touch screen with stable transmitting PLC control to perform bag making, weighing, filling, sealing, code printing, and cutting automatically.

    2. Independent compressed air control and electrical wire system control separately, low noise in running, stable performance.

    3. Vacuum belt pulling system to feed film and make bags with no faults.

    4. Double servo control system, precise positioning.

    5. Easy to palce the rewind rolls onto the machine.

    6. Set uo and adjust parameters on touch screen to change bag size.

    7. Sealed structure design to prevent dust contamination.

    8. Multi computerized weighing heads to deliver correct weight.


    Application:


    The bagging machine is widely used for packing of products in shape of granules, stripes, slices, such as candy, potato chips, jelly, and peanuts.


    Specifications:


    Mode

    HTL-V520


    Bag length(mm)

    80-400(L)


    Bag width(mm)

    80-250(W)


    Max width of roll film(mm)

    520


    Packing speed(bags/min)

    5-50


    Volumn range

    3000Max


    Air consumption(Mpa)

    0.65


    Gas consumption(m3/min)

    0.4


    Power voltage

    220V


    Power(KW)

    4


    Dimension(L*W*H)mm

    1150*1795*1650


    Weight(kg)

    600






    14 Head Weighing Vertical Packaging Machine For Candy14 Head Weighing Vertical Packaging Machine For Candy
